1997 Ninja® ZX™-6R - Battery Case

DOWNLOAD PDF
SELECT A NEW PART
130
130A
130A
550
11012
11012
11012A
11048
11048A
27012
27012
27012A
27012B
32037
34003
34003
35011
35011A
35011B
35011C
46075A
46075C
92015
92015A
92150
92150
92150A
92150A
92150A
92150A
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
BOLT-FLANGED,6X14,BLACK 130 130J0614 2
BOLT-FLANGED,8X30 130A 130J0830 4
PIN-COTTER,4.0X25 550 550D4025 1
CAP,BUNGEE CORD HOOK 11012 11012-1589 2
CAP 11012A 11012-1844 1
BRACKET,FUEL PUMP 11048 11048-1859 1
BRACKET,RADIATOR 11048A 11048-1860 1
HOOK,BUNGEE CORD,RR 27012 27012-1475 2
HOOK,HELMET,LH 27012A 27012-1505 1
HOOK,HELMET,RH 27012B 27012-1506 1
BRACKET-SHOCKABSORBER 32037 32037-1657 1
HOLDER-STEP 34003 34003-1327 2
STAY,FR,LH 35011 35011-1552 1
STAY,FR,RH 35011A 35011-1553 1
STAY,REAR STEP,LH 35011B 35011-1736 1
STAY,REAR STEP,RH 35011C 35011-1737 1
GRIP,RR,LH,F.BLACK 46075A 46075-1115-21 1
GRIP,RR,RH,F.BLACK 46075C 46075-1116-21 1
NUT,FLANGED,16MM 92015 92015-1881 1
NUT,16MM 92015A 92015-1953 1
BOLT,SOCKET,10X25 92150 92150-1268 2
BOLT,SOCKET,8X20 92150A 92150-1839 8
