2000 Lakota 300 - Front Fender(s)

DOWNLOAD PDF
SELECT A NEW PART
130
130A
180
11044
11044
11048
14024
14024A
14090
35004
35004A
35011
35011A
35011B
35019
35019A
92009
92009A
92009A
92009A
92009B
92009B
92009B
92009B
92009B
92009B
92009C
92011
92011
92015
92015
92015
92015A
92015A
92015A
92015B
92027
92027
92027A
92027B
92075
92075A
92075A
92075B
92075C
92143
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
BOLT-FLANGED,6X35 130 130G0635 2
BOLT-FLANGED,6X12 130A 130P0612 4
BOLT-UPSET-WS,6X35 180 180D0635 2
BRACKET,FLAP 11044 11044-1934 2
BRACKET,HEAD LAMP COVER 11048 11048-1742 1
COVER,FRONT FENDER,BLACK 14024 14024-1268-6D 1
COVER,FRONT FENDER,INNER 14024A 14024-1297 1
COVER,HEAD LAMP,BLACK 14090 14090-1495-6D 1
FENDER-FRONT,H.GREEN 35004 35004-1379-6A 1
FENDER-FRONT,F.RED 35004A 35004-1379-6L 1
STAY,FRONT FLAP,LH,SILVER 35011 35011-1694-5A 1
STAY,FRONT FLAP,RH,SILVER 35011A 35011-1695-5A 1
STAY,FR FENDER,BLACK 35011B 35011-1697-10 1
FLAP,LH 35019 35019-1172 1
FLAP,RH 35019A 35019-1173 1
SCREW,6X18,BLACK 92009 92009-1181 2
SCREW,6X22,BLACK 92009A 92009-1256 4
SCREW,6X14 92009B 92009-1288 16
SCREW,16MM 92009C 92009-1508 2
SCREW 92011 92011-562 2
NUT,LOCK,FLANGED,6MM 92015 92015-1675 4
NUT,CLAMP,6MM 92015A 92015-1678 6
NUT 92015B 92015-1701 1
COLLAR,L=13.1,BLACK 92027 92027-1450 2
COLLAR,L=5.6 92027A 92027-1933 2
COLLAR,L=4.7 92027B 92027-1964 2
DAMPER,DUAL SEAT 92075 92075-023 1
DAMPER 92075A 92075-1690 2
DAMPER 92075B 92075-1834 2
DAMPER 92075C 92075-1936 2
COLLAR,L=19.6 92143 92143-1100 2
