1976 JS400 - CARBURETOR

DOWNLOAD PDF
SELECT A NEW PART
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
CARBURETOR 1 16001-3003-YR 1
.SPRING 2 92081-529 1
.GASKET 3 92065-529 1
.'E'RING 4 92036-512 1
.THROTTLE SHAFT ASSY 5 59111-519 1
.SPRING,CABLE PULLY 6 16040-022 1
.SCREW,4X20 7 92009-3009 1
.BOLT,4X8 8 92001-3026 2
.SPRING 9 92081-525 1
.CHOKE SHAFT ASS'Y 10 59111-513 1
.SCREW,LOW SPEED 11 59271-506 1
.SPRING 12 92081-528 1
.WASHER 13 92022-537 1
."0" RING 14 92055-510 1
.SCREW 3X5 15 92011-517 2
.VALVE,CHOKE 16 16126-3001 1
."0" RING,DRAIN PLUG 17 92055-1093 1
.WASHER 18 92065-528 1
.SPRING 19 92081-534 1
.SCREW,HIGH SPEED 20 59271-507 1
.SCREW 2.3X3 21 92011-506 1
.GASKET 22 92065-520 1
.SCREW 4X30 23 92011-515 6
.SCREW 3X7 24 92011-516 2
.VALVE,THROTTLE 25 16025-503 1
.FLOAT PIN 26 16032-006 1
.ARM 27 59001-506 1
.SCREW 3X7 28 92011-516 1
.WASHER FLOAT VLV SEAT 29 16029-004 1
.VALVE-SEAT 30 16030-503 1
.SPRING 31 92081-536 1
.DIAPHRAGM,MAIN 32 51069-502 1
.GASKET 33 11060-3704 2
.BODY,DIAPHRAGM(1) 34 59021-514 1
.DIAPHRAGM,PUMP 35 43028-3002 1
.BODY,DIAPHRAGM(2) 36 59336-3002 1
.GASKET 37 11060-3705 1
.DIAPHRAGM,PUMP 38 43028-3001 1
.BODY,DIAPHRAGM(3) 39 59336-3003 1
.GASKET 40 92065-526 1
.FILTER 41 14037-504 1
.SCREW 4X12 42 92011-510 1
.COVER-CARB. SIDE 43 59036-530 1
.GASKET 44 92065-530 1
.DIAPHRAGM,CHECK SEAT 45 51069-501 1
.PLATE 46 59086-509 1
.SCREW 3X7 47 92011-516 2
.BANJO-CARB 48 59071-505 1
.GASKET-BANJO BOLT 49 92065-078 2
.BOLT,BANJO 50 92003-521 1
