Parts Diagrams |
| ITEM NAME | REF # | PART NUMBER | QUANTITY | DESTINATION | REMARKS |
|---|---|---|---|---|---|
| PLATE,PILOT LAMP | 13169 | 13169-1136 | 1 | ||
| COVER,METER BRACKET | 14025 | 14025-1101 | 1 | ||
| COVER,METER | 14025A | 25012-025 | 2 | ||
| SOCKET,TACHOMETER | 23008 | 23008-1004 | 1 | ||
| SOCKET,SPEEDOMETER | 23008A | 23008-1006 | 1 | ||
| SOCKET,PILOT LAMP | 23008B | 23008-1023 | 1 | ||
| LAMP ASSY,PILOT | 23016 | 23016-1013 | 1 | ||
| SPEEDOMETER,MPH | 25005 | 25005-1060 | 1 | ||
| BRACKET,METER | 25008 | 25008-1013 | 1 | ||
| TACHOMETER ASSY | 25015 | 25015-1007 | 1 | ||
| COVER,INDICATER LAMP | 25023 | 25023-1011 | 1 | ||
| BOLT,HEX HEAD,6X14 | 92001 | 92003-204 | 4 | ||
| SCREW,TAPPING,4X10 | 92009 | 92009-1040 | 2 | ||
| SCREW-CSK-RD-CROS,4X4 | 92009A | 222C0445 | 2 | ||
| NUT | 92015 | 92015-078 | 4 | ||
| NUT-CAP,5MM | 92015A | 322C0500 | 4 | ||
| WASHER,5.2X16X16X1.2T | 92022 | 25009-004 | 4 | ||
| WASHER 6.5X20X1.6T | 92022A | 92022-125 | 2 | ||
| WASHER-SPRING,6MM,BLA | 92022B | 461K0600 | 4 | ||
| BULB 12V 3W | 92069 | 92069-018 | 7 | ||
| DAMPER RUBBER-METER | 92075 | 25019-013 | 4 | ||
| SHOCK DAMPER,SPEEDMET | 92075A | 25019-031 | 2 | ||
| DAMPER,PILOT LAMP | 92075B | 92075-1138 | 2 | ||
| DAMPER RUBBER,METER | 92075C | 92075-248 | 4 | ||
| NUT 6MM | 311 | 311B0600 | 2 | ||
| WASHER PLAIN 6MM | 411 | 411B0600 | 4 |
