2020 KX™65 - Engine Mount

DOWNLOAD PDF
SELECT A NEW PART
11053
132
550
92015
92015A
92015A
92022
92022
92022A
92066
92066
92122
92122A
92143
92150
92153
92153
92171
92180
92180
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
BRACKET,IGNITER 11053 11053-1682 1
BOLT-FLANGED-SMALL,8X40 132 132BA0840 1
PIN-COTTER,2.5X18 550 550AA2518 1
NUT,FLANGED,8MM 92015 92015-1406 1
NUT,8MM 92015A 92015-1432 2
WASHER 92022 92022-107 2
WASHER,8.5X20X1.6 92022A 92022-1561 1
PLUG 92066 92066-1081 2
ROLLER,CHAIN GUIDE 92122 92122-1179 1
ROLLER,CHAIN GUIDE 92122A 92122-1213 1
COLLAR,9.5X12.7X25 92143 92143-1432 1
BOLT,6X12 92150 92150-1891 1
BOLT,FLANGED,8X110 92153 92153-1095 2
CLAMP,L=60 92171 92171-0652 1
SHIM,9X18X0.3 92180 92180-1354 AR
