The complex shape of the impeller is 3D machined from forged aluminum for high precision and durability. The impeller spins at 9.2x speed of the crankshaft, reaching speeds of nearly 130,000 rpm, pumping a capacity of over 200 liters of air per second into the engine.

Designed using technology from Kawasaki Heavy Industries., Ltd. (KHI) Aerospace Company, the planetary gear transfers power from the crankshaft to drive the impeller to incredibly high rpm.

The balanced supercharged engine delivers both exhilarating acceleration and superb fuel efficiency. The key to achieving this balance was increasing the engine’s thermal efficiency by utilizing a high compression ratio. Designed for high-performance racing engines, the premium dog-ring transmission allows for smooth, precise, quick shifting. Rather than shifting gears into place, the gears in this configuration stay in place, with the lightweight dog rings moving to engage the gears. A high-quality hydraulic Assist and Slipper clutch minimizes wheel chatter caused by rapid downshifting and self-adjusts to ensure consistent performance and smooth actuation.

The Ninja H2™ motorcycle utilizes Kawasaki Intelligent anti-lock Brake System (KIBS) technology and comes equipped with dual radial-mount opposed four-piston Brembo Stylema® front calipers and semi-floating 330mm discs for aggressive braking. The Brembo clutch and front brake levers were designed to prevent wind force from engaging the levers while at higher speed.

The lightweight cast aluminum wheels were designed specifically for the Ninja H2™ and were created using analysis from Kawasaki’s World Superbike team. Star-pattern 5-spoke wheels offer optimum rigidity for high-power performance and feature pinstripes for a prestigious image. Bridgestone Battlax RS11 sport tires contribute to sharp handling.

This system allows riders to set engine braking according to preference. When the system is activated, the engine braking effect is reduced, providing less interference when riding on the circuit.

Complementing the engine’s strong power and the dog-ring transmission, a contactless-type quick shifter enables quick upshifts for seamless acceleration. The KQS enables clutchless downshifts for quick and smooth deceleration.

Bluetooth® Smartphone Connectivity (using RIDEOLOGY THE APP*) connects you with your bike like never before, allowing you to view vehicle info, riding log, phone notifications, and general settings.

Three-mode KLCM provides unmatchable acceleration from a stop by electronically controlling engine output to minimize rear wheel-slip and front end lift. Launch Control Mode allows the rider to launch from a stop with the throttle held wide open.

The trellis frame provides the strength to harness the incredible power of the supercharged engine and the balanced flex to achieve optimal rigidity and pliability for aggressive sport riding.

Features a special top coat on all non-carbon bodywork parts that allows certain types of scratches to repair themselves, enabling the paint to maintain its high-quality finish through normal wear and tear*. Self-healing is achieved through microscopic soft and hard segments within the top coat to work like a chemical spring that creates a trampoline effect to absorb impacts.

All-digital TFT (thin-film transistor) color instrumentation gives the cockpit a high-tech, high-grade appearance and visibility. The screen’s background color is selectable (black or white), and screen brightness adjusts automatically to suit available light.

Display functions include: digital speedometer, digital bar-style tachometer, gear position indicator, shift lamp, fuel gauge, odometer, dual trip meters, current and average fuel consumption, remaining range, average speed, total time, coolant temperature, clock, battery voltage, Kawasaki service reminder, oil change reminder and the Kawasaki Economical Riding Indicator.

For a bright and more efficient look, all light equipment utilizes LED technology, including turn signals and license plate lamp.
