2026 TERYX®5 H2 DELUXE eS - Rear Fender(s)
35023
35023A
35023B
35023C
35023D
35023E
36043
36043A
36043B
39028
39137
39137A
49106
49106A
92015
92015
92015
92015
92015
92015
92015
92015
92015
92015
92015
92015
92015
92039
92039
92039
92039
92039
92039
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92039A
92152
92152
92152
92154
92154
92154
92154
92154
92154
92154
92154
92154A
92154A
92154A
92154A
92172
92173
92173
130
130
130
130
130A
130A
| ITEM NAME | REF # | PART NUMBER | QUANTITY | DESTINATION | REMARKS |
|---|---|---|---|---|---|
| FENDER-REAR,LWR,LH,L.GREEN | 35023 | 35023-0518-777 | 1 | ||
| FENDER-REAR,LWR,RH,L.GREEN | 35023A | 35023-0519-777 | 1 | ||
| FENDER-REAR,UPP,LH,L.GREEN | 35023B | 35023-0520-777 | 1 | ||
| FENDER-REAR,UPP,RH,L.GREEN | 35023C | 35023-0521-777 | 1 | ||
| FENDER-REAR,FLARE,LH | 35023D | 35023-0522 | 1 | ||
| FENDER-REAR,FLARE,RH | 35023E | 35023-0523 | 1 | ||
| COVER-TAIL,LH | 36043 | 36043-0008 | 1 | ||
| COVER-TAIL,RH | 36043A | 36043-0009 | 1 | CN | |
| COVER-TAIL,RH | 36043B | 36043-0012 | 1 | CA,US | |
| BUMPER-REAR | 39028 | 39028-0014 | 1 | ||
| STAY-COMP,RR FENDER,LH | 39137 | 39137-0779 | 1 | ||
| STAY-COMP,RR FENDER,RH | 39137A | 39137-0780 | 1 | ||
| COVER-MUFFLER,LH | 49106 | 49106-0917 | 1 | ||
| COVER-MUFFLER,RH | 49106A | 49106-0918 | 1 | ||
| NUT,CLAMP,6MM | 92015 | 92015-1678 | 16 | ||
| RIVET,3.2X14.2 | 92039 | 92039-0744 | 12 | ||
| RIVET | 92039A | 92039-0865 | 42 | ||
| COLLAR,6.3X9.5X4.1 | 92152 | 92152-1571 | 4 | ||
| BOLT | 92154 | 92154-2474 | 10 | ||
| BOLT | 92154A | 92154-3957 | 6 | ||
| SCREW,TAPPING,6X16 | 92172 | 92172-0869 | 2 | ||
| CLAMP | 92173 | 92173-1423 | 4 | ||
| BOLT-FLANGED,8X12 | 130 | 130BA0812 | 4 | ||
| BOLT-FLANGED,6X14 | 130A | 130CA0614 | 2 |
